Performance And Characteristics:

1. Automatic feeding section

    High-speed stable feeder free from maintenance.

    Options: movable guide rail, manual feeding table for paper

    size feeder could not handle.

2. Powder-removing section

    Adopt flannel roller and heating roller double way to clean

    the powder on paper surface and increase the coating effects,

    convenient adjustment and operation.

3. Grounding coating / IR drying section

    This section is used for water-based varnish before UV coating

    to fill with small holes on paper surface to save UV varnish.

4. Infrared hot air drying / cooling fan Ministry

    The unique design of hot-wind drying make water-based

coating drying faster and more purely.

5. UV coating / UV curing section

    Adopt reverse roller and speed regulating to control varnish

    thickness, automatic stop for paper jam to reduce sheets to be

    wasted.

6. UV curing

    This section is composed of lamps, reflectors, air cooling

    and exhausting systems. Sheets coated by UV varnish will

    be dried here.

7. Automatic delivery section

    Jogging times can be set according to paper weight. Pneumatic

    joggers keep sheets delivered orderly. Equip with counter for

    coated sheets, pre-delivery table which will be automatically

    open when paper jam in delivery.

8. Machine PLC control, man-machine dialogue.

● Air knife system for light paper more than 80gsm is optional.
